4.00mm Special-shaped PCB Board
4.00mm Special-shaped PCB Board is a PCB engineering reference project from ULIKE. The case highlights schematic review, layout optimization, stack-up planning, impedance-aware routing, and manufacturability checks, with original process notes covering 异形板，TG170，8层板.
Ask About Similar ProjectsProcess notes
- 异形板，TG170，8层板
- 2多层板能批量生产2层至10层，6层和8层HDI板子可小量生产。
- 3最小线宽/间距：3mil/3mil BGA间距:0.25MM左右(三星6410)
- 4成品最小孔径：0.1mm
- 5最大尺寸:610mmX1200mm
- 6油墨：日本Tamura、Taiyo感光油墨；
Delivery attention
- Provide mechanical limits, connector positions and keep-out areas before layout starts.
- Confirm stack-up, impedance and key signal requirements early to reduce board revision.
- Before fabrication, review Gerber, drill, paste mask and assembly drawings together.
Project record
ULIKE used this 4.00mm special-shaped pcb board case to demonstrate practical PCB design support for manufacturable layouts, faster prototype cycles, and engineering documentation. Key technical notes include: 异形板，TG170，8层板; 2多层板能批量生产2层至10层，6层和8层HDI板子可小量生产。; 3最小线宽/间距：3mil/3mil BGA间距:0.25MM左右(三星6410); 4成品最小孔径：0.1mm; 5最大尺寸:610mmX1200mm; 6油墨：日本Tamura、Taiyo感光油墨；.
